DBA 5000 series Drilled and Dimpled Rotor Only Right Hand DBA52068.1RXD

DBA 5000 Series HD – Smooth OE Style Rotor Finish

The DBA 5000 Series HD variant features a smooth, OE-style rotor surface without any slots, cross-drilled holes, or dimples. It is the ideal solution for drivers who want the advanced performance and construction of the 5000 Series but prefer a plain rotor face for reduced noise and an OEM look.

Like all 5000 Series rotors, the HD variant is built using a high carbon cast-iron ring and aerospace-grade T6061-T6 aluminium hat, offering superior thermal performance, reduced unsprung weight, and reusability of the hat with DBA replacement rings.

Note: 5000 Series HD part numbers are not marked with any specific suffix.

Technical information:

Diameter [mm]: 390
Thickness [mm]: 35,6
Disc Vent: 72 Curved Vanes
Annulus [mm] (Maximum useable pad width): 71,5
Pitch Circle Diameter (P.C.D.): 228,6
Inside Diameter [mm]: 247
Diameter & Number of Bolt Holes [mm]: 6.4 (x12)
Air Gap [mm]: 17
Offset [mm]: 0
Flange Inside Diameter [mm]: 208
Flange Thickness [mm]: 7
Hole Type: Round Hole
Stage: Stage 5
Tech Bulletins: Bedding-In Brakes | Motorsport Information
Replacement Nuts: Included

Suitable for:

N/A
