GARRETT 851154-5004S TURBOCHARGER GTX3582R GEN 2 A/R 0.70 450-900 HP (W/O HOUSING)

The GTX GEN 2 is the next evolution of GTX line with major updates and new technology. Updates include a compressor wheel aero update that gives it the ability to produce up to 20% more horsepower than the previous version.

GTX GEN 2 compressor wheels were designed using proprietary Garrett Motion computer simulation technology focusing on CFD analysis to optimize the wheel design to reach maximum efficiency and mass flow for each turbocharger.

Features

• Gen 2 Aero forged milled compressor wheel
• High-Flow compressor housing with integrated speed sensor port
• Rotation: Standard
• Dual ceramic ball bearing cartridges
• Inconel turbine wheel
• Water and oil cooled
• Compressor side: Inducer 66mm / Exducer 83mm
• Turbine side: Inducer 68mm / Exducer 62mm
• Power Rating: 450 - 900 HP
• Displacement: 2.0 - 4.5 L

Product category: Turbocharger
